Down4Sound TCX 10" 2700W RMS Subwoofer DVC

The DOWN4SOUND TCX 10” Subwoofer D2 delivers serious power in a compact package. Engineered for tight-space builds, daily drivers, or high-output demo setups, the TCX-10 features a 2700W RMS rating, oversized motor structure, and a 3-inch 8-layer flat aluminum voice coil for exceptional thermal handling.

A carbon fiber cone and stitched high-roll surround allow deep excursion without distortion, while the 5-stack Y35 motor and extensive venting ensure the sub stays cool under pressure. Designed for maximum performance in minimum space, the TCX-10 D2 is small, smart, and savage.

QUICK NOTES

• RMS Handling: 2700W RMS
• Coil Size: 3 Inch – 8 Layer Flat Aluminum
• Impedance: Dual 2 Ohm (D2)
• Cutout Diameter: 9.25 inches / 235 mm
• Mounting Depth: 7.6 inches / 193 mm
• Weight: ~60 lbs
• Xmax: ~30 mm (one-way)
• Motor Size: 240 mm (9.45 in)
• Highly extended pole piece for maximum excursion
• Dual flared pole vent for airflow and noise reduction
• Rear gap venting for coil temperature management

PRECISION ENGINEERING

With a BL product around 28.578 T·m, the TCX-10 D2 maintains precise control under pressure. The 8-layer coil construction enhances current handling and heat dissipation, allowing this subwoofer to maintain output and reliability under extended use. The carbon fiber cone is ultra-light yet rigid, producing fast, punchy bass without breakup.

If you want to run serious power in a small build — this is the 10” that acts like a 12.

TECHNICAL SPECIFICATIONS

• Resonance Frequency (Fs): 39.760 Hz
• Sd: 113.411 cm²
• Mms: 430.207 g
• BL: 28.578 T·m
• Qms (Mechanical Q): 4.011
• Qes (Electrical Q): 0.678
• Qts (Total Q): 0.582
• No (Efficiency): 0.074%
• Sensitivity (SPL): 80.5 dB
• Vas: 7.070 L
• Cms: 37.795 μm/N
• Krm: 53.788 mOhm
• Erm: 0.538
• Kxm: 103.337 mH
• Exm: 0.618

RECOMMENDED ENCLOSURE

• Ported Box Volume: 1.5 – 1.75 cu ft
• Tuning Frequency: 34 Hz

Built to hit hard and last long, the TCX-10 D2 is your go-to for tight, loud, and clean bass.
